Navigator Short Progressive

Lens Features

Branded Soft, Multi Design asymmetrical lens

Guaranteed adaptation

Slow progression of power

Slow progression of power

No swims effect, distortion in viewing zones

Navigator Poly-ideal for Rimless & Supra frame

Benefit to Customer

Good design at economical rate

Branded ARC & Hard coated lenses

Good adaptability

Ideal for bifocal users

Optimized & Balanced vision

Suitable for all types of frame

Technical Specification

SPECIFICATION OF LENSES

Hard or Soft Design                         Soft

NAVIGATOR SHORT

Asymmetrical

Yes

Aspheric Distance Area                   Yes

Width of Far Vision

29.5 mm

Navigator Normal Design Mapping

Average Corridor Width                   6.9mm

Reading Width at 12 mm below fit point

13.9 mm

Reading Width at 14 mm below fit point 17.8 mm

Corridor Length

16 mm

Maximum Astigmatism                 2.00 Diopter

Temporal/Nasal Softness of Design

1.75/2.00 D

Clear Distance Angle From Fit Point     170 degree

Softness of Design

0.19 D

Minimum Fitting height                   16 mm

Suggested Fitting Height

18 mm

Navigator Regular Progressive (Min Fitting Height 18mm)

Lens Type

Navigator Short Progressive 1.50 **        +5.00/-8.00 with 4 Cyl               <c

Water Mark

Navigator Short Poly Progressive 1.59 **  +5.00/-8.00 with 4 Cyl               <c

Note: ** For Above 4 Cyl Added Rs.300/Piece

Power Range
